2 in. Stainless Steel Full Port Socket Weld 1000# Ball Valve
Milwaukee Valve
30 Series 2 in. Stainless Steel Full Port Socket Weld 1000# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 1
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
Milwaukee Valve
30 Series
2 in. Stainless Steel Full Port Socket Weld 1000# Ball Valve
39147A
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Frequently Purchased Together
Product Details
Product Details
- Locking lever for safety lockout
- Multiple v-ring stem packing arrangement for longer packing life
- Vent hole in ball slot for cavity venting
- TFE/graphite body seal
- Blow-out proof stem
- NACE compliant for sour gas service
- Cantilever seat design for low operating torque
- Meets ASME, MSS-SP and ASTM specifications
- 1000 WOG
- Actuator mounting pads
Specifications
- ASTM:
- ASTM A-276, ASTM A-351 CF8M, ASTM A-479, ASTM A-744 CF8M, ASTM F-593
- Clean Bagged:
- No
- Collection:
- 30 Series
- End Connection 1:
- Socket Weld
- End Connection 2:
- Socket Weld
- End Connections:
- Socket Weld
- FM Approved:
- No
- Handle Material:
- Stainless Steel
- IAPMO Listed:
- No
- Lead Law Compliance Level:
- Lead Free Not Certified, Approved for Non-Potable Water Applications
- Length:
- 6-1/10 in
- MSS:
- MSS SP-110
- Material:
- Graphite, Stainless Steel
- Material Type:
- 316, CF8M
- Maximum Temperature:
- 500
- NSF Certified:
- No
- Pressure - High:
- 150, 1000
- Pressure Class:
- 1000#
- Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Recommended Valve Application:
- Gas, Oil, Steam, Water
- UL Listed:
- No
- UPC:
- 697988490505
- Valve Body Style:
- 3 piece
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- 15% Glass Filled RPTFE
- Valve Size:
- 2 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
